Hydraulic Nuts
EziTite® Hydraulic Clamp Nuts define the modern era, ensuring accurate and reliable loading for precise tool clamping. They seamlessly replace traditional torque-loaded threaded nuts, making shaft tensioning a streamlined, hydraulically assisted process. Expertly tailored for various applications, these nuts accommodate threads ranging from 50 mm to 300 mm, positioning them as the go-to for industries globally.
Product Features:
- Hydraulic Advantage: Simplifies the process and enhances safety.
- Diverse Sizing: Available from 50 mm to 300 mm threads; custom sizes on request.
- Reduced Downtime: Significantly minimises maintenance challenges.
Handy For:
- Situations demanding accurate and reliable loading on bolting.
- Environments with vibrational or torsional stresses.
- Scenarios where repeated adjustment or removal of nuts is frequent.
The EziTite® Hydraulic Nut is precision engineered to offer reliable tensioning. These high-pressure, high-performance hydraulic nuts redefine bolt tensioning, ensuring every bolted joint achieves an extremely accurate load. Compatible with Technofast pumping equipment, they simplify complex tasks.
Product Features:
- Precision Engineered: Crafted for high-pressure performance.
- Multiple Tensioning: Even loading across all fasteners for optimal results.
- Compact Design: Perfect for difficult or confined spaces.
Handy For:
- Situations with vibrational or torsional stresses.
- Circumstances requiring frequent repeated adjustments.
- Settings with difficult nut locations.
The EziTite® TR Hydraulic Nut encapsulates Technofast’s commitment to excellence. With a patented metal-to-metal seal design, it’s crafted to withstand temperatures upwards of 550˚C. Compact, yet powerful, it’s the ultimate solution for high-temperature bolt tensioning in tight spaces.
Product Features:
- High-Temperature Resilience: Rated for applications up to 550˚C and beyond.
- Innovative Design: Combats load losses and ensures reliable and precise tensioning.
- Secondary Release Mechanism: Features a 'sacrificial ring' for added safety.
Handy For:
- High-temperature settings like pressure vessel closures (Autoclaves, Boilers).
- Bolted joints in flange makeup processes.
- Gas and steam turbine joints.
Introducing the EziTite® Hydraulic Head Nut – an innovative replacement for traditional mantle Head Nuts. Recognising the long-standing challenges faced in the quarrying industry, particularly in ensuring safe and effective tightening of mantle head nuts, the EziTite® Hydraulic Head Nut emerges as a game-changer. More than just a hydraulic nut, it places a premium on operator safety, addressing risks associated with shrapnel injuries from standard methods. Its design embraces hydraulic clamping capabilities, and is complemented by an integral sacrificial protective cover tailored to the abrasive nature of crushed materials.
Product Features:
- Hydraulic Precision: Generates clamping forces via hydraulic pressure on a constrained EziTite® area.
- Mechanical Locking: Fitted with locking rings, ensuring accurate and reliable loading.
- Safety Mechanisms: In case of hydraulic issues, a patented breaker ring facilitates easy load release.
Handy For:
- Mantle Head Nut applications, specifically in Gyratory Crushers.
The EziTite® Hydraulic Washer is an exemplary variant of the EziTite® Hydraulic Nut, precision engineered for specific bolted joint applications. Instead of the conventional threaded body, this hydraulic washer is equipped with a non-threaded bore. This design change ensures that the load is exerted on the top and bottom faces of the tool. Such a configuration is optimal for tensioning two parallel surfaces, making it ideal for scenarios involving large diameter bolts or when extremely accurate tensioning between two surfaces is paramount.
Product Features:
- Unique Design: Non-threaded bore, ensuring direct pressure on top and bottom tool faces.
- Precision Engineered: Tailored for reliable and precise tensioning between parallel surfaces.
- Efficiency: Reduces the need for repeated adjustment, ensuring consistent bolted joint quality.
Handy For:
- Applications demanding accurate and reliable loading between parallel surfaces.
- Environments where bolted joint quality and tensioning precision are paramount.
- Situations involving large diameter bolts and multiple tensioning needs.
How do Hydraulic Nuts Work?
A hydraulic nut applies direct axial tension to a bolt using internal hydraulic pressure instead of traditional rotational torque. This advanced method entirely removes thread friction, providing an exceptionally accurate, repeatable, and safe bolt load across critical mechanical joints.
- Fit the Nut: Thread the hydraulic nut tensioner assembly onto the bolt or stud until it seats against the flange interface surface.
- Apply Pressure: Connect a high-pressure hydraulic pump to the tool to push the internal piston upward and stretch the bolt axially.
- Lock the Collar: Spin the integrated mechanical locking ring or collar down to lock the elongated bolt stretch firmly in place.
- Release the Pump: Vent the internal hydraulic fluid pressure, allowing the joint to carry the fully retained clamping load safely.
Related Equipment
- Hydraulic Bolt Tensioners: Pairs with our high-performance EziJac® tensioners for direct, variable axial stud stretching applications.
- Hydraulic Bolts: Combines with advanced EziTite® hydraulic bolt configurations to provide internal structural clamping tension without external nuts.
- CamNut & Bearing Setters: Utilise compact hydraulic mechanical locking arrangements with the CamNut and for rapid, precision bearing installation sequences, our EziTite® Bearing Setter is optimised to mount heavy industrial bearings with completely repeatable accuracy
